Aiways U5 63 kWh - Official Range and Energy Consumption (Combined)
WLTP Range (TEL*): 410 km 254.8 mi
WLTP Range (TEH*): 400 km 248.5 mi
WLTP Consumption (TEL*): 16.6 kWh/100 km 26.7 kWh/100 mi
WLTP Consumption (TEH*): 17 kWh/100 km 27.4 kWh/100 mi
Petrol/Gasoline equivalent: 1.87 l/100 km 126.2 MPGe
* TEL (Test Energy Low) indicates the lowest values (most economical) with the lightest set of options TEH (Test Energy High) indicates the highest values (least economical) with the heaviest set of options
Aiways U5 63 kWh - Battery
Battery Type: Lithium-ion
Battery Capacity Gross: 63 kWh
Battery Capacity Useable: 60 kWh
Aiways U5 63 kWh - Dimensions and Weights
Body Type: SUV
Length: 4680 mm 184.25 in
Width: 1865 mm 73.43 in
Height: 1700 mm 66.93 in
Wheelbase: 2800 mm 110.24 in
Weight: 1720 kg 3792 lbs
Trunk / Boot Space: 432 l 15.3 ft3
Trunk / Boot Space Max: 1555 l 54.9 ft3
Frunk Space:50 l 1.8 ft3
Max Tow Hitch Load: 75 kg 165 lbs
Max Trailer Load Braked: 1500 kg 3307 lbs
Max Trailer Load Unbraked: 750 kg 1653 lbs
Ground Clearance: 150 mm 5.91 in
Tire Standard: 235/50 R19
Seats max.: 5
Aiways U5 63 kWh - Charging
AC On-Board Charger Standard: 6.6 kW
DC Fast Charging: 90 kW
Charge Port: CCS
Charge Port Location: Front Left
Aiways U5 63 kWh - AC Charging Times (home, work, hotel)
Select State of Charge (SOC):
The maximum on-board charger power of the Aiways U5 63 kWh is 6.6 kW. All figures in the table above are assumed approximate values under optimal conditions.
Aiways U5 63 kWh - DC Fast Charging Times
Select State of Charge (SOC):
The maximum fast charging power of the Aiways U5 63 kWh is 90 kW. All figures in the table above are assumed approximate values under optimal conditions.
The technical information on this page are used from official data provided by the car companies and figures measured by our editorial staff and/or other independent persons. For further details, please visit the manufacturer's website. If you think any of the information is wrong, please let us know.
