BMW iX1 eDrive20 Tech Specs

from: 2023

other variants:

Compare all variants side by side

BMW iX1 eDrive20 - Prices

Price in the United Kingdom of Great Britain and Northern Ireland (GBP)
On The Road Price
£46,205

Show prices of all variants

Price in Germany (EUR)
Preis inkl. MwSt.
48.400 €

Show prices of all variants

Battery Capacity Gross/Useable 66.4​/​64.7 kWh

Range (WLTP) 475 km 295.2 mi

Minimal Consumption (WLTP) 15.4 kWh/100 km 24.8 kWh/100 mi

Acceleration 0-100 km/h 8.6 s

Acceleration 0-60 mph 8.3 s

BMW iX1 eDrive20 - Performance Specs

  • Power: 150 kW (201 hp)
  • Torque: 250 Nm 184 lb-ft
  • Number of Engines: 1
  • Drive: Front
  • Acceleration 0-60 mph: 8.3 s
  • Acceleration 0-100 km/h: 8.6 s
  • Acceleration 0-62 mph: 8.6 s
  • Top Speed: 170 km/h 106 mph

BMW iX1 eDrive20 - Official Range and Energy Consumption (Combined)

  • WLTP Range (TEL*): 475 km 295.2 mi
  • WLTP Range (TEH*): 430 km 267.2 mi
  • WLTP Consumption (TEL*): 15.4 kWh/100 km 24.8 kWh/100 mi
  • WLTP Consumption (TEH*): 17.2 kWh/100 km 27.7 kWh/100 mi
  • Petrol/Gasoline equivalent: 1.73 l/100 km 136 MPGe

* TEL (Test Energy Low) indicates the lowest values (most economical) with the lightest set of options
TEH (Test Energy High) indicates the highest values (least economical) with the heaviest set of options

BMW iX1 eDrive20 - Battery

  • Battery Type: Lithium Nickel Manganese Cobalt (NMC)
  • Battery Capacity Gross: 66.4 kWh
  • Battery Capacity Useable: 64.7 kWh

BMW iX1 eDrive20 - Dimensions and Weights

  • Body Type: SUV
  • Length: 4500 mm 177.17 in
  • Width: 1845 mm 72.64 in
  • Height: 1642 mm 64.65 in
  • Wheelbase: 2692 mm 105.98 in
  • Weight: 1980 kg 4365 lbs
  • Max Payload: 570 kg 1257 lbs
  • Trunk / Boot Space: 490 l 17.3 ft3
  • Trunk / Boot Space Max: 1495 l 52.8 ft3
  • Frunk Space:doesn't have a frunk
  • Max Roof Load: 75 kg 165 lbs
  • Ground Clearance: 205 mm 8.07 in
  • Seats max.: 5

BMW iX1 eDrive20 - Charging

  • AC On-Board Charger Standard: 11 kW
  • AC On-Board Charger Optional: 22 kW
  • DC Fast Charging: 130 kW
  • Charge Port: CCS
  • Charge Port Location: Right Rear

BMW iX1 eDrive20 - AC Charging Times (home, work, hotel)

Select State of Charge (SOC):

The maximum on-board charger power of the BMW iX1 eDrive20 is 11 kW, optional charger 22 kW.
All figures in the table above are assumed approximate values under optimal conditions.

BMW iX1 eDrive20 - DC Fast Charging Times

Select State of Charge (SOC):

The maximum fast charging power of the BMW iX1 eDrive20 is 130 kW.
All figures in the table above are assumed approximate values under optimal conditions.

BMW iX1 eDrive20 - Others

  • Platform: BMW FAAR
  • Dedicated EV Platform: No
  • Drag Coefficient Cd: 0.26

BMW iX1 - Interior And Exterior Photos

BMW iX1 - front BMW iX1 - rear BMW iX1 - side BMW iX1 - front BMW iX1 - rear BMW iX1 - rear BMW iX1 - front BMW iX1 - side BMW iX1 - rear BMW iX1 - Image 10 from the photo gallery BMW iX1 - Image 11 from the photo gallery BMW iX1 - interior BMW iX1 - interior BMW iX1 - interior BMW iX1 - interior seats BMW iX1 - front seats BMW iX1 - rear seats BMW iX1 - trunk / boot BMW iX1 - interior BMW iX1 - Image 20 from the photo gallery BMW iX1 - Image 21 from the photo gallery BMW iX1 - Image 22 from the photo gallery BMW iX1 - Image 23 from the photo gallery BMW iX1 - tech specs BMW iX1 - charging

BMW iX1 - Safety - Crash Tests

Euro NCAP: This is a test of the ICE version.

The technical information on this page are used from official data provided by the car companies and figures measured by our editorial staff and/or other independent persons. For further details, please visit the manufacturer's website.
