Ford F-150 Lightning Standard Range Tech Specs

from: 2021

other variants:

Compare all variants side by side

Ford F-150 Lightning Standard Range - Prices

Price in the United States of America (USD)
Base Price (MSRP) Destination Charge Effective Price
$62,995 $1,995 $64,990

Show prices of all variants

Battery Capacity Gross/Useable 108​/​98 kWh

Range (WLTP) 386 km 239.8 mi

Minimal Consumption (WLTP) 25.3 kWh/100 km 40.7 kWh/100 mi

Approach Angle (degrees) 25.4, Departue Angle (degrees) 24.2, Breakover Angle (degrees) 17.8

Ford F-150 Lightning Standard Range - Performance Specs

  • Power: compare 337 kW (452 hp)
  • Torque: compare 1050 Nm 774 lb-ft
  • Number of Engines: 2
  • Drive: compare 4x4
  • Top Speed: compare 177 km/h 110 mph

Ford F-150 Lightning Standard Range - Official Range and Energy Consumption (Combined)

  • WLTP Range (TEL*): compare 386 km 239.8 mi
  • WLTP Consumption (TEL*): compare 25.3 kWh/100 km 40.7 kWh/100 mi
  • Petrol/Gasoline equivalent: 2.85 l/100 km 82.8 MPGe

* TEL (Test Energy Low) indicates the lowest values (most economical) with the lightest set of options
TEH (Test Energy High) indicates the highest values (least economical) with the heaviest set of options

Ford F-150 Lightning Standard Range - Battery

  • Battery Type: Lithium Nickel Manganese Cobalt (NMC)
  • Battery Capacity Gross: compare 108 kWh
  • Battery Capacity Useable: compare 98 kWh

Ford F-150 Lightning Standard Range - Dimensions and Weights

  • Body Type: Pick-up
  • Length: compare 5911 mm 232.72 in
  • Width: compare 2032 mm 80 in
  • Height: compare 2004 mm 78.9 in
  • Wheelbase: 3696 mm 145.51 in
  • Max Payload: 907 kg 2000 lbs
  • Trunk / Boot Space: compare 1495 l 52.8 ft3
  • Frunk Space: compare400 l 14.1 ft3
  • Max Trailer Load Braked: 3493 kg 7701 lbs
  • Ground Clearance: compare 226 mm 8.9 in
  • Min Turning Circle (curb-curb): compare 15.6 m 51.2 ft
  • Tire Standard: 275/65 R18
  • Seats max.: 5

Ford F-150 Lightning Standard Range - Charging

  • AC On-Board Charger Standard: 11.3 kW
  • DC Fast Charging: compare 150 kW
  • Charge Port: CCS
  • Charge Port Location: Front Left

Ford F-150 Lightning Standard Range - AC Charging Times (home, work, hotel)

Select State of Charge (SOC):

The maximum on-board charger power of the Ford F-150 Lightning Standard Range is 11.3 kW.
All figures in the table above are assumed approximate values under optimal conditions.

Ford F-150 Lightning Standard Range - DC Fast Charging Times

Select State of Charge (SOC):

The maximum fast charging power of the Ford F-150 Lightning Standard Range is 150 kW.
All figures in the table above are assumed approximate values under optimal conditions.

Ford F-150 Lightning Standard Range - Others

  • Platform: TE1
  • Dedicated EV Platform: Yes
  • Drag Coefficient Cd: compare 0.56

Ford F-150 Lightning - Interior And Exterior Photos

Ford F-150 Lightning - colors Ford F-150 Lightning - Image 2 from the photo gallery Ford F-150 Lightning - front Ford F-150 Lightning - driving shot Ford F-150 Lightning - Image 5 from the photo gallery Ford F-150 Lightning - driving Ford F-150 Lightning - Image 7 from the photo gallery Ford F-150 Lightning - Image 8 from the photo gallery Ford F-150 Lightning - Image 9 from the photo gallery Ford F-150 Lightning - towing Ford F-150 Lightning - frunk Ford F-150 Lightning - truck bed Ford F-150 Lightning - front headlight Ford F-150 Lightning - interior front seat Ford F-150 Lightning - interior Ford F-150 Lightning - interior Ford F-150 Lightning - interior touchscreen Ford F-150 Lightning - interior touchscreen Ford F-150 Lightning - cockpit display Ford F-150 Lightning - interior Ford F-150 Lightning - charging Ford F-150 Lightning - app Ford F-150 Lightning - platform battery

Compare the parameters of all the Ford F-150 Lightning variants

The technical information on this page are used from official data provided by the car companies and figures measured by our editorial staff and/or other independent persons. For further details, please visit the manufacturer's website.
